Rohde Ecotop 60S Kiln
Item: ECOTOP60S
Description
The Rohde Ecotop kilns have new internal designs. They are currently one of the most economical kilns on the market and feature new and unique insulations concept that allows for very high energy efficiency. Suitable for temperatures to 1320°C.
CEE Plug & Cable Supply
The Ecotop60S available either as a single or three phase kiln. A qualified electrian is required to wire it in. to Please check your supply before purchasing.
5kW/23A 230V single phase, 32 amp 3-pin CEE plug and cable
5kW/7.5A (per phase) 400V three phase, 16 amp 5-pin CEE plug and cable.
2 - Layer Insulation Concept
Including super-efficient thermal bricks and 15 mm microporous insulating board.
Reversible Kiln Stand
The kiln stand can be turned upside-down. This allows the kiln to be used at two different working heights. The toploader can be adjusted to your individual needs and makes loading and unloading of the firing chamber much easier on the back.
Kanthal A1 Elements
The Ecotop range, utilises Kanthal A1 elements (which are widely regarded as the best quality elements available), ensuring unbeatable reliability and durability.
New Rounder Chamber Geometry
Optimised combustion chamber geometry thanks to new alignment of the lightweight refractory bricks and thus even more combustion chamber utilisation.
New Gas Pressure Spring-Supported Opening Mechanism
The sturdy lid construction is supported by gas pressure springs that allow easy, effortless and safe opening of the lid.
Connectivity With Mykiln App
Controllers work with ‘Mykiln App’. Watch and edit your kiln firings from the comfort of your armchair.
Solid-State Relays
Power control effected by silent, low-wear solid-state relays with an external cooling element
Specifications
Application Temp °C - 1290
Max Temp °C - 1320
Capacity (l) - 60L
Int Dimensions (mm) - ø400 x 455(h)
Ext Dimensions (mm) - W-755 x D-730 x H-775
Output - 5 kW
Current - 23A
Electrical Connection - 1-Phase
Weight - 86kg
Optional Kiln Furniture Set Includes:
2 x Shelves - 350mm Dia x 10mm
3 x 25mm props
3 x 50mm props
3 x 75mm props
3 x 100mm props
For costs on firing, see Rohde's website. Rohde say the calculations are accurate for any kW version of each model size
Delivery Details & Guarantee
- Delivery times subject to availability
- Delivery is to your driveway only and does not include installation. Please consider that you may need help to situate the kiln.
- Delivered directly from the supplier. If you order other items at the same time as your kiln, they will arrive separately.
- Delivery is an all day delivery, please contact us if you need a timed delivery window as there may be a charge.
Our Palletised Delivery Guidance shows you what to expect upon delivery.
On arrival see how your Rohde Toploader is packed.
Guarantee
- 3 Year Manufacturers Warranty (not including elements).
Controllers & App
The new European ST 310 Stafford controller uses its simple firing graph to easily see what stage your firing is in. The ST 310 is a standard issue with a Rohde kiln but you can upgrade to the ST 411 for more program spaces and segments.
Visit the Rohde website for more information on the ROHDEgraph app.
Standard ST310
- 32 programs with 2 segments
- 2 controlled heating ramps, 1 controlled soak period and 1 controlled cooling ramp
Upgrade ST411
- 32 programs with up to 32 segments each
- 1 additional switch output
- 1 controlled heating/cooling ramp + soak period per segment
Both Controllers
- Current ROHDE controllers are optimised for operation with a PV system (ST 411 PV)
- Soak times up to 99 hours 59 mins
- Ramp rates from 1 to 999°C/h or “FULL”
- USB port and Wi-Fi module for data logging via the ROHDEgraph and the ROHDE myKiln App / SolarReady (PV / photovoltaics)
- ROHDE SolarReady configuration optional
- Programs can be altered while firing
- Program pause and advance function
- Lockable keypad
- Program start delay facility – up to 99 hours 59 mins
- Recovery in the event of a power failure
- Displays energy used
- Setpoint display
- Alarm buzzer
- Temperature values can be displayed in °C or °F
- ROHDE CPC 14 connector
